74-Gallon Atmospheric Vent Commercial Gas Water Heater

Model CGN075075 400
Capacity (Gallons)
Fuel Source

  • Delivers 73 GPH at 100°F Rise
  • Fully automated controls with safety shutoff
  • Patented eco-friendly Green Choice® Gas Burner design reduces NOx emissions by up to 33% and complies with Low-NOx emission requirements
  • 74-Gallon Atmospheric Vent Commercial Gas Water Heater
    Model CGN075075 400
    Product Details
    • Delivers 73 GPH at 100°F Rise
    • Fully automated controls with safety shutoff
    • Patented eco-friendly Green Choice® Gas Burner design reduces NOx emissions by up to 33% and complies with Low-NOx emission requirements
    • Innovative anode design delivers advanced tank corrosion protection
    • Push-button piezo ignitor makes lighting pilot fast & easy
    • Patented Blue Diamond® glass tank lining protects against corrosion
    • Enhanced flow brass drain valve designed for easy maintenance and easy operation
    • Eco-Friendly non-CFC foam insulation, external heat traps and specially designed combustion chamber combine for maximum savings on operating costs
    • Factory-installed heat trap nipples for faster installation
    • 3-year limited tank and 1-year limited parts warranty

    • Features fully automated controls with safety shutoff that is accurate, dependable control system requires no electric connections. Provide reliable, efficient service for applications such as office buildings and duplex/fourplex apartment homes.

    Specifications
    Tech Specs
    Nominal Gallon Capacity
    74 Gallons
    Rated Storage Volume
    71 Gallons
    Thermal Efficiency
    80%
    Maximum BTUs
    75.100
    Power Source
    GAS
    Limited Tank Warranty
    3 Years
    Limited Parts Warranty
    1 Years
    ASME Certified
    No
    Destination Country
    US
    Fuel Source
    NATURAL
    Installation Type
    INDOOR
    Application
    COMMERCIAL
    Shipping Height
    60.75"
    Shipping Length
    29"
    Shipping Width
    31.25"
    Side Loop
    No
    Dimension & Venting
    Type
    Water Heater
    Diameter
    26.39 in."
    Shipping Weight
    270 lbs
