Product Details
- Self-Cleaning
- Inlet/outlet connections located top, front and rear for greater installation flexibility
- Space-saving units are up to one foot shorter than models they replace
- Installs standalone, manifolded or connected to storage tanks
- Glasslined Tank with Multiple Anode Rods
- Anode rods with stainless steel core provide additional corrosion protection
- Intermittent electronic ignition eliminates standing pilot, saving energy
- Self-cleaning system reduces sediment build-up, maintaining rated thermal efficiency and reducing water heating costs (operates when cold water is connected through front)
- Factory-installed, CSA Certified and ASME Rated T&P Relief Valve
- 3-year limited tank and 1-year limited parts warranty
The original money-saving self-cleaning water heater. It provides outstandingperformance and installation flexibility for new construction and replacement applications.
Offers installer-friendly features, including compact low-profile
design, multiple options for water connections and low installation clearances.
Specifications
Tech Specs
Nominal Gallon Capacity
100 Gallons
Rated Storage Volume
98 Gallons
Thermal Efficiency
80%
Maximum BTUs
275.000
Power Source
GAS
Limited Tank Warranty
3 Years
Limited Parts Warranty
1 Years
T&P Relief Valve
Yes
ASME Certified
No
Amperes
5
Destination Country
US
Fuel Source
NATURAL
Height to T&P
56,00
Installation Type
INDOOR
Application
COMMERCIAL
Shipping Height
80"
Shipping Length
41"
Shipping Width
34"
Side Loop
No
Voltage
120
Dimension & Venting
Type
Water Heater
Height
72"
Diameter
30.25 in."
Shipping Weight
720 lbs
Height to Gas Valve
4.5"
Vent Material
Steel
