Product Details
- Easy Installation - Simply plugs into a standard 120 volt wall outlet. Top water connections make it easy to replace an existing gas water heater. The 120V also has smaller room size requirements and integrated duct adapters for installation in confined spaces.
- Whisper-Quiet Operation - Operation at 45 dBA. No accessory vibration isolation kit required.
- Leak Protection Technology - The smart sensor alerts the user in the event of a leak. The included water shutoff valve automatically closes when a leak is detected to block the cold water supply to reduce property damage.
- Easy To Control - Digital control makes it simple to set to preferred water temperature.
- Automatic shut-off valve closes valve on incoming cold water inlet when leak is detected to reduce property damage
- Equipped with a CTA-2045-A (AC) utility communication port to allow for participation in utility demand response programs for added energy savings
- Utilizes R-513A refrigerant which has 56% lower global warming potential than the standard R-134a refrigerant used in other heat pump water heaters
- Dual 900 Watt elements, 120 VAC 60Hz single phase 15 amp shared circuit
- Glass tank lining protects against corrosion
- 10-year limited tank and parts warranty
The 120V Plug-In Hybrid Electric heat pump water heater makes it easier than ever for consumers to electrify to an energy-efficient option to save money on their utility bills. These models plug into a standard wall outlet for easy installation. Top water connections make it easy to replace an existing gas water heater.
Specifications
Tech Specs
Nominal Gallon Capacity
66 Gallons
Rated Storage Volume
68 Gallons
UEF
3.2
Power Source
ELECTRIC
Limited Tank Warranty
10 Years
Limited Parts Warranty
10 Years
T&P Relief Valve
Yes
Water Connection Location
TOP
Water Connection Size
0.75"
First Hour Rating
76 Gallons
ASME Certified
No
NEEA Certified
true
Amperes
9.38
Destination Country
US
Digital Display
true
ENERGY STAR® Certified
true
Height to T&P
38.25
Installation Type
INDOOR
Max Wattage
900
Number of Elements
2
Application
RESIDENTIAL
Shipping Height
70"
Shipping Length
32"
Shipping Width
28.25"
Side Loop
No
Voltage
120
Dimension & Venting
Type
Water Heater
Height
64"
Diameter
26.5 in."
Width
26.5"
Shipping Weight
289lbs
