Product Details
- 80,000 Btu/Hr
- 95% AFUE
- 10:1 Turndown Ratio
- 2" Venting up to 100'
- Universal Vent Connector
- Features SMART CONTROL™ Operating Control
- 10 Yr Warranty
Noble® is easy to install, set up and service, and promises to deliver the lasting reliability and serviceability the industry has come to expect from a Lochinvar boiler.
Specifications
Tech Specs
Maximum BTUs
80,000
Power Source
GAS
Limited Parts Warranty
5 Years
Water Connection Size
1"
AFUE
95.00
ASME Certified
Yes
ASME Stamp
H
Destination Country
US
ENERGY STAR® Certified
true
Fuel Source
NATURAL
Height to Gas Valve
4.12
Ignition Type
Direct Spark
Installation Type
INDOOR
Limited Heat Exchanger Warranty
10 Years
Minimum BTUs
8,300.00
Application
RESIDENTIAL
Shipping Height
28"
Shipping Length
45"
Shipping Width
22"
Side Loop
No
Vent Material
Stainless Steel, polypropylene, PVC, CPVC
Voltage
120
Dimension & Venting
Type
Boiler
Height
32.876"
Width
17.0625"
Shipping Weight
123lbs
Product Literature
Sales Brochures
Submittals
Product Summary
Manuals
Parts Sheet
Revit Product Drawings
Energy Guide
