Product Details
- Equipped with Demand Response (CTA-2045 EcoPortCM) communication port for Utility Demand Response program participation (Module needed from local utility)
- Meets state of Washington and Oregon Grid Capable requirements
- User friendly controls to set operating modes & review diagnostics
- Dual 4,500-watt commercial-grade heating elements deliver reliable and efficient hot water
- Long-lasting lower Incoloy™ stainless steel element
- Durable glass tank lining protects against corrosion
- Automatic cleaning system protects against sediment build-up
- Tank saver anode rod protects against corrosion longer than ordinary anodes
- Commercial-grade brass drain valve for durable and easy operation
- CSA Certified and ASME Rated T&P Relief Valve, Factory-Installed
Take advantage of advanced utility savings with Grid-Capable water heaters. The built-in CTA-2045 port allows homeowners to connect to local Utility Smart Grid Programs where available.
Specifications
Tech Specs
Nominal Gallon Capacity
55 Gallons
Rated Storage Volume
55 Gallons
UEF
0.94
Power Source
ELECTRIC
Limited Tank Warranty
6 Years
Limited Parts Warranty
6 Years
T&P Relief Valve
Yes
Water Connection Location
TOP
Water Connection Size
0.75"
First Hour Rating
75 Gallons
ASME Certified
No
Blanket Included
No
Destination Country
US
Digital Display
Yes
Height to T&P
48.50
Installation Type
INDOOR
Max Wattage
4,500
Number of Elements
2
Application
RESIDENTIAL
Shipping Height
60.63"
Shipping Length
28.25"
Shipping Width
25.13"
Side Loop
No
Voltage
240
Dimension & Venting
Type
Water Heater
Height
56.5"
Diameter
24 in."
Shipping Weight
145 lbs
