Product Details
- Heat pump storage tanks are optimized for heat pump domestic hot water applications requiring long duration recovery periods
- Proprietary stratification design provides 95% draw down
- Commercial-grade magnesium anode rods provide additional protection against corrosion
- All tanks are constructed to the requirements of the ASME
- 5” thick foam insulation with a value of R30, exceeds minimum ASHRAE and U. S. Department of Energy thermal insulation requirements
- Heavy gauge steel cabinet with high quality paint for added durability
- Furnished with two 3” bolted flange circulating connections for ease of installation
- 127 PSI ASME standard working pressure
- 10-year limited tank / 1-year limited parts warranty
These storage tanks are optimized for heat pump domestic hot water applications requiring long duration recovery periods. Designed to take full advantage of heat pump systems, a unique baffle reduces water turbulence into and out of the tank to prevent disruption of the stratified layers. This allows for draw down of 95%, delivering more hot water from a given capacity. R30 insulation value helps to significantly reduce standby loss.
Specifications
Tech Specs
Nominal Gallon Capacity
450 Gallons
Limited Tank Warranty
5 Years
Limited Parts Warranty
1 Years
Water Connection Size
3"
ASME Certified
Yes
ASME Stamp
HLW
Destination Country
US
Application
COMMERCIAL
Shipping Height
72"
Shipping Length
107"
Shipping Width
68"
Side Loop
No
Dimension & Venting
Type
Tank
Height
100"
Shipping Weight
1356 lbs
Product Literature
Sales Brochures
Submittals
Typical Specification
Revit Product Drawings
