Solution Heating Boiler

Model CBL090
Fuel Source
Maximum BTU's

  • 90,000 Btu/Hr Input
  • Gasketless Heat Exchanger
  • Intermittent Spark Ignition
  • Solution Heating Boiler
    Model CBL090
    Product Details
    • 90,000 Btu/Hr Input
    • Gasketless Heat Exchanger
    • Intermittent Spark Ignition
    • Terminal Strips
    • Built-In Performance Loop
    • Temperature Control with Domestic Hot Water Prioritization and Outdoor Temperature Reset
    • Optional PVC or CPVC Vent Kit
    • 20-Yr Limited Warranty on Heat Exchanger
    • 84% AFUE

    • Lochinvar designed the Solution to make installations a snap in any home with all piping and venting connections made conveniently from the top of the unit. The Solution is also pre-piped with a pumped performance loop for easy hookup. Lightweight and compact, the Solution’s flexibility allows the contractor to spend less time installing your new boiler, which results in savings to you.

    Specifications
    Tech Specs
    Maximum BTUs
    90,000
    Power Source
    GAS
    Limited Parts Warranty
    2 Years
    Water Connection Size
    1.5"
    AFUE
    84.00
    ASME Certified
    Yes
    ASME Stamp
    H
    Destination Country
    US
    Fuel Source
    PROPANE
    Height to Gas Valve
    6.75
    Ignition Type
    Intermittent/Electronic
    Installation Type
    INDOOR
    Limited Heat Exchanger Warranty
    20 Years
    Minimum BTUs
    90,000.00
    Application
    RESIDENTIAL
    Shipping Height
    35"
    Shipping Length
    28"
    Shipping Width
    27"
    Side Loop
    No
    Vent Material
    B-Vent
    Voltage
    120
    Dimension & Venting
    Type
    Boiler
    Height
    29.5"
    Width
    21.5"
    Shipping Weight
    175lbs
    Vent Type
    Atmospheric Vent
