Standard Hi-Power® 50-Gallon Commercial Electric Water Heater

Model LHC-50 P12 100
Capacity (Gallons)
ASME Indicator

  • Designed for use as a recovery water heater
  • Meets ASHRAE/IES 90.1-2004
  • Heavy-duty incoloy sheathing elements provide excellent protection against oxidation and scaling
  • Standard Hi-Power® 50-Gallon Commercial Electric Water Heater
    Model LHC-50 P12 100
    Product Details
    • Designed for use as a recovery water heater
    • Meets ASHRAE/IES 90.1-2004
    • Heavy-duty incoloy sheathing elements provide excellent protection against oxidation and scaling
    • Power circuit fusing protects elements and contractors from short circuits, overloading or line surges
    • Factory installed terminal block for ease of installation
    • Advanced electronic control for ease of operations and diagnostics
    • Dual commercial-grade anode rods for maximum corrosion protection
    • Simplified circuitry, color coded for ease of service
    • 3-year limited tank and 1-year limited parts warranty

    • The Standard Hi-Power commercial electric water heaters are designed for use as recovery water heaters for hot water supply service or as boosters for supplying sanitizing rinse water for dish washing. The water heaters display detailed operational and diagnostic information including fault and alert messages if an operational issue occurs. Advanced control system automatically lowers the operating set point by a programmed value during user-defined time periods to help reduce operating costs during unoccupied or low demand periods.

    Specifications
    Tech Specs
    Nominal Gallon Capacity
    50 Gallons
    Rated Storage Volume
    46 Gallons
    Limited Tank Warranty
    3 Years
    Limited Parts Warranty
    1 Years
    T&P Relief Valve
    Yes
    ASME Certified
    No
    Destination Country
    US
    Max Wattage
    12,300
    Number of Elements
    3
    Application
    COMMERCIAL
    Shipping Height
    64"
    Shipping Length
    30"
    Shipping Width
    25"
    Side Loop
    No
    Voltage
    240
    Dimension & Venting
    Type
    Water Heater
    Shipping Weight
    265lbs
    Product Literature
