Product Details
- Designed for use as a recovery water heater
- Glass lining provides super protection against corrosion
- Durable commercial-grade copper heating elements
- Factory installed terminal block for ease of installation
- Temperature controls located behind hinged control compartment door for quick, easy access.
- Commercial-grade anode rod provides maximum tank protection from corrosion
- Most models convert to three-phase or single-phase in field for easy installation
- 3-year limited tank and 1-year limited parts warranty
Our light duty commercial electric water heaters are built to the same high quality standards as our gas models. They can be installed for non-simultaneous and single element operation, or for simultaneous dual-element operation.
Specifications
Tech Specs
Nominal Gallon Capacity
66 Gallons
Rated Storage Volume
60 Gallons
Thermal Efficiency
98%
Power Source
ELECTRIC
Limited Tank Warranty
3 Years
Limited Parts Warranty
1 Years
T&P Relief Valve
Yes
Water Connection Location
TOP
Water Connection Size
0.75"
ASME Certified
No
Blanket Included
No
Destination Country
US
Height to T&P
60.75
Installation Type
INDOOR
Max Wattage
12,200
Number of Elements
2
Application
COMMERCIAL
Shipping Height
62.5"
Shipping Length
24.5"
Shipping Width
24.5"
Side Loop
No
Voltage
277
Dimension & Venting
Type
Water Heater
Height
60.75"
Diameter
21.75 in."
Width
18"
Shipping Weight
158 lbs
