Product Details
- Designed for use as a recovery water heater
- Meets ASHRAE/IES 90.1-2004
- Heavy-duty incoloy sheathing elements provide excellent protection against oxidation and scaling
- Fusing protects all elements, thermostats, and internal wiring circuits against excess current flow
- Factory installed terminal block for ease of installation
- Temperature controls located behind hinged control compartment door for quick, easy access.
- Dual commercial-grade anode rods for maximum corrosion protection
- Simplified circuitry, color coded for ease of service
- 3-year limited tank and 1-year limited parts warranty
The surface thermostat on each heating element is designed for 120°F to 180°F high water temperature operation for food service and other commercial applications.
Specifications
Tech Specs
Nominal Gallon Capacity
50 Gallons
Rated Storage Volume
46 Gallons
Limited Tank Warranty
3 Years
Limited Parts Warranty
1 Years
T&P Relief Valve
Yes
ASME Certified
No
Destination Country
US
Digital Display
true
Max Wattage
12,300
Number of Elements
3
Application
COMMERCIAL
Shipping Height
62"
Shipping Length
30"
Shipping Width
25"
Side Loop
No
Voltage
240
Dimension & Venting
Type
Water Heater
Shipping Weight
233lbs
Product Literature
Typical Specification
Manuals
Parts Sheet
Revit Product Drawings
Archive
