Product Details
- Designed for use as a recovery water heater
- Meets ASHRAE/IES 90.1-2004
- Heavy-duty incoloy sheathing elements provide excellent protection against oxidation and scaling
- Fusing protects all elements, thermostats, and internal wiring circuits against excess current flow
- Factory installed terminal block for ease of installation
- Temperature controls located behind hinged control compartment door for quick, easy access.
- Dual commercial-grade anode rods for maximum corrosion protection
- Simplified circuitry, color coded for ease of service
- 3-year limited tank and 1-year limited parts warranty
The surface thermostat on each heating element is designed for 120°F to 180°F high water temperature operation for food service and other commercial applications.
Specifications
Tech Specs
Nominal Gallon Capacity
80 Gallons
Rated Storage Volume
73 Gallons
Power Source
ELECTRIC
Limited Tank Warranty
3 Years
Limited Parts Warranty
1 Years
T&P Relief Valve
Yes
Water Connection Size
0.75"
ASME Certified
No
Blanket Included
No
Destination Country
US
Digital Display
true
Height to T&P
52.15
Installation Type
INDOOR
Max Wattage
12,300
Number of Elements
3
Application
COMMERCIAL
Shipping Height
69.25"
Shipping Length
34.5"
Shipping Width
27.75"
Side Loop
No
Voltage
240
Dimension & Venting
Type
Water Heater
Height
60.25"
Diameter
25.25 in."
Width
25.5"
Shipping Weight
314lbs
