Product Details
- ENERGY STAR® certified
- Continuous flow rate up to 10.0 GPM
- Integrated recirculation pump
- Primary commercial-grade copper heat exchanger is 25x better than stainless steel at heat transfer, stabilizing outgoing water temperatures quicker
- Secondary heat exchanger is made of 316L Stainless Steel to protect against corrosion
- Highly efficient condensing Ultra-Low Nox tankless water heater delivers up to .95 Uniform Energy Factor (UEF)
- Common vent up to 8 units, Easy-Link 540P with three other 540H to increase flow capacity
- Includes a wall mount temperature remote controller and advanced diagnostics to simplify troubleshooting
- Safety features include exhaust & water temperature safety control, overheat cut-off fuse and air-fuel ratio (AFR) sensor
- 15-year limited warranty on heat exchanger in residential applications
The 540P series integrates a recirculation pump to provide instant hot water in residential applications with dedicated recirculation lines. The pump is easily controlled with a simple user interface and multiple pump settings allow you to customize pump operation to meet your needs while maximizing heater efficiency. As part of the high efficiency tankless family, the 540P series provides endless hot water while being environmentally friendly.
Specifications
Tech Specs
UEF
0.95
Maximum BTUs
199,000
Power Source
GAS
Limited Tank Warranty
15 Years
Limited Parts Warranty
5 Years
Water Connection Location
BOTTOM
Emissions
Ultra-Low NOx
ASME Certified
No
Destination Country
US
ENERGY STAR® Certified
true
Fuel Source
PROPANE
Installation Type
OUTDOOR
Limited Heat Exchanger Warranty
15 Years
Max Flow Rate
5.8 GPM
Minimum BTUs
13,000.00
Application
RESIDENTIAL
Shipping Height
33.25"
Shipping Length
21.75"
Shipping Width
15.625"
Side Loop
No
Dimension & Venting
Type
Water Heater
Shipping Weight
70lbs
