Product Details
- Delivers 83-gallon first hour rating
- 40,000 BTU input atmospheric vent design
- Gas Burner, meets or exceeds emission requirements in California & Utah
- Push-button piezo ignitor makes lighting pilot fast & easy
- Intelligent electronic gas control provides precise temperature control and LED status indicator
- Glass tank lining protects against corrosion
- Automatic cleaning system protects against sediment build-up
- Stainless steel tank saver anode rod protects against corrosion longer than ordinary anodes
- Commercial-grade brass drain valve for durable and easy operation
- 8-year limited tank and parts warranty
The 40-Gallon Ultra-Low Nox Atmospheric Vent Tall Natural Gas Water Heater delivers an efficient, reliable performance and features an innovative design that protects against accidental ignition of flammable vapors.
Specifications
Tech Specs
Nominal Gallon Capacity
40 Gallons
Rated Storage Volume
38 Gallons
UEF
0.64
Maximum BTUs
40,000
Power Source
GAS
Limited Tank Warranty
8 Years
Limited Parts Warranty
8 Years
T&P Relief Valve
Yes
Water Connection Location
TOP
Water Connection Size
0.75"
Emissions
Ultra-Low NOx
First Hour Rating
83 Gallons
ASME Certified
No
Blanket Included
No
Destination Country
US
Flue Diameter
4.00
Fuel Source
NATURAL
Height to Gas Valve
11.00
Height to T&P
51.75
Ignition Type
Pilot with Piezo Igniter
Installation Type
INDOOR
Application
RESIDENTIAL
Shipping Height
62.31"
Shipping Length
24"
Shipping Width
21"
Side Loop
No
Dimension & Venting
Type
Water Heater
Height
58.25"
Diameter
20 in."
Shipping Weight
146lbs
Vent Type
Atmospheric Vent
Product Literature
Sales Brochures
Parts Sheet
Archive
Warranty
Energy Guide
