Product Details
- 399,000 BTU/HR
- 99% Thermal Efficiency
- Up to 150' Equivalent Vent Lengths
- 10:1 Turndown Ratio
- Condensing Stainless Steel Heat Exchanger
- SMART TOUCH™ Operating Control
- CON·X·US® Remote Connect Capable
- Pump Included
- 5 Year Limited Warranty
With ten models from 400,000 to 4,000,000 Btu/hr input, ARMOR will service a large range of commercial applications and add the "green" touch that building owners and facility managers desire.
Specifications
Tech Specs
Nominal Gallon Capacity
4.5 Gallons
Thermal Efficiency
99%
Maximum BTUs
399,000
Power Source
GAS
Limited Parts Warranty
1 Years
Water Connection Location
BACK
Water Connection Size
2"
Emissions
Low NOx
ASME Certified
Yes
ASME Stamp
HLW
Destination Country
US
ENERGY STAR® Certified
true
Flue Diameter
4.00
Fuel Source
NATURAL
Height to Gas Valve
29.12
Installation Type
INDOOR
Limited Heat Exchanger Warranty
5 Years
Minimum BTUs
39,900.00
Application
COMMERCIAL
Shipping Height
54"
Shipping Length
51"
Shipping Width
30"
Side Loop
No
Voltage
120
Dimension & Venting
Type
Water Heater
Height
45"
Shipping Weight
386lbs
Vent Type
Direct Vent
