Product Details
- 1,999,000 BTU/HR
- 98% Thermal Efficiency
- Up to 150' Equivalent Vent Lengths
- 5:1 Turndown Ratio
- Condensing Stainless Steel Heat Exchanger
- SMART TOUCH™ Operating Control
- CON·X·US® Remote Connect Capable
- Pump Included
- 5 Year Limited Warranty
With ten models from 400,000 to 4,000,000 Btu/hr input, ARMOR will service a large range of commercial applications and add the "green" touch that building owners and facility managers desire.
Specifications
Tech Specs
Thermal Efficiency
98%
Maximum BTUs
1,999,000
Power Source
GAS
Limited Parts Warranty
1 Years
Water Connection Location
BACK
Water Connection Size
2.5"
Emissions
Low NOx
ASME Certified
Yes
ASME Stamp
HLW
Destination Country
US
ENERGY STAR® Certified
true
Fuel Source
PROPANE
Height to Gas Valve
55.38
Installation Type
INDOOR
Limited Heat Exchanger Warranty
5 Years
Minimum BTUs
400,000.00
Application
COMMERCIAL
Shipping Height
72"
Shipping Length
44"
Shipping Width
91"
Side Loop
No
Voltage
208
Dimension & Venting
Type
Water Heater
Height
56.625"
Shipping Weight
1911lbs
Vent Type
Direct Vent
